QA3 Patient Trolley

Lightweight, robustly built and ergonomically designed, this range of patient transport stretchers is ideal for use in hospitals and other clinical environments.

Standard Features

• Full length moulded plastic side rails drop down below the mattress support surface to allow unimpeded access for patients and virtually no gap when laterally transferring to or from a bed. Raising and lowering the side rails is almost effortless due to the counterbalanced pivot mechanism controlling movement.
• Hydraulic assist height adjustment, using foot controls, accessible from both sides of trolley; exceptional low height for easy and safe patient access
• Collapsible two stage IV pole, mounted to the outside of the side rail, at the head end. When not required, it folds down into a storage cavity, moulded into the side rail panel.
• Hydraulic assist Trendelenburg function operated from hand control at side of trolley
• 5th wheel steering significantly improves manoeuvrability and is engaged using foot pedal at the rear of trolley
• Ergonomically positioned fold down push handles, at the head end, plus another set of fixed push handles behind the backrest reduce effort required when manoeuvring trolley during patient transfers
• K8 pressure care mattress consisting of dual layer of hospital grade foam, with a viscoelastic memory foam top layer for additional pressure relief; mattress enclosed in a latex-free, breathable, vapour permeable 4 way stretch PU cover, with RF welded seams, for improved infection control
• Gas assist backrest function, activated from hand control behind patient’s head
• Central locking brakes accessed from both sides of trolley, front and rear
• Oxygen cylinder storage troughs moulded into both sides of ABS plastic cover over trolley base
• Rotating buffers on all four corners of trolley
• 320kg SWL
